Calculate the maximum stresses in the end plate, Mechanical Engineering

Assignment Help:

The end plate of a tube is made from 4mm thick steel plate as seen in the figure below. If a 30mm diameter rod welded to the plate is subjected to a force of 10kN, what would be the movement of the rod? Calculate also the maximum stresses in the end plate.

2090_Calculate the maximum stresses in the end.png

E= 208GN/m^2, v =0.287.
